steel truss arch bridge

  • Image 15 of 17

Image Description

details of the steel arch bridge structure at the southern end of the golden gate bridge, metal box trusses form an arch to distribute the load while the main suspension cable passes inbetween from borrom left to top right

arch structure bridge arch metal red painted bridge detail closeup arched girders cross braces
