cantilever bridge

The famous forth rail bridge in Scotland, the cantilever design was chosen after the failure of a bridge similar to the original design proposed. the bridge is considered an engineering masterpiece of the Victorian era, each tower is 100m tall and stands on large stone caissons

Image 8 of 22

Image Description

The famous forth rail bridge in Scotland, the cantilever design was chosen after the failure of a bridge similar to the original design proposed. the bridge is considered an engineering masterpiece of the Victorian era, each tower is 100m tall and stands on large stone caissons

Keywords: Edinburgh Scotland forth bridge forth rail bridge cantilever metal structure caisson firth of forth
Resolution:: 3500 x 2329
File size:: 1295 kB

Download Image

License Details

Creative Commons Attribution 4.0 License
This image must be attributed - see license details
