helical scanning


  • Image 67 of 70

Image Description

internal mechanism of a video recorder, the drum seen at the centre left of the picture contains scanning head which when spinning read diagonal 'slices' of analgoue video information from a relatively slow moving tape as it passes the over the spinning drum

Keywords
metal mechanical vcr video recorder analog analogie scanning helical scanning magnetic tape reader mechanism drum shiny polished
