Disassembled remote control


  • Image 48 of 70

Image Description

Disassembled remote control lying in three parts showing the case, buttons or keypad and the electronic circuitry. The buttons are formed of flexible rubber and a conductive carbon pad which connects to pads on the circuitboard when the button is pressed

Keywords
case circuitry control disassembled electronics keypad remote communication infrared television conductive carbon
